| Frequency Response |
: |
50 Hz - 20 kHz
(+1, -1.5 dB) |
|
| Enclosure Resonance Frequency |
: |
38 Hz |
|
Low Frequency
Extension |
: |
User controls
set to default |
|
|
|
|
|
Low-High Frequency
Crossover |
: |
1.7 kHz 6th-order acoustic Linkwitz-Riley |
|
| Distortion, 96 dB SPL, 1m |
: |
N/A |
|
| Mid-High Frequency (120 Hz - 20 kHz) |
: |
N/a |
|
|
|
|
|
| Maximum SPL (80 Hz - 20 kHz) |
: |
>108 dB SPL / 1m |
|
| Maximum Peak SPL (80 Hz - 20 kHz) |
: |
>111 dB SPL / 1m |
|
| Signal Input |
: |
Neutrik “Combi” XLR-1⁄4-in tip-ring-sleeve balanced or unbalanced positive voltage applied to XLR pin 2 (1⁄4" tip) produces outward woofer motion |
|
| Calibrated Input Sensitivity, XLR & 1⁄4" |
: |
N/A |
|
| +4 dBu / +8 dBu |
: |
96 dB SPL / 1 m |
|
| -10 dBV |
: |
96 dB SPL / 1 m |
|
| AC Input Voltage |
: |
100 / 240 VAC |
|
|
|
| Long-Term Maximum System Power |
: |
220 W (IEC265-5) |
|
| Self-Generated Noise Level |
: |
<+10 dBA / 1 m Tonal-artifact-free |
|
